Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty

    Buy cheap Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty from wholesalers

    Buy cheap Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty from wholesalers
    • Buy cheap Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty from wholesalers

    Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty

    Ask Lasest Price
    Brand Name : HJY
    Model Number : P5
    Certification : CE FCC
    Price : negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 1000sqm per month
    Delivery Time : 15-20days after receiving deposit
    • Product Details
    • Company Profile

    Indoor P3 P4 P5 P6 LED Curtain Wall Display Smooth Surface 2 Years Warranty


    indoor P3 P4 P5 P6 hd led video wall,factory directly sale led display


    screens


    Specification

    ItemParameters
    ModuleModule size320 x 160mm
    Pixel pitch5mm
    Pixel density40000 pixels/ sqm
    Pixel configuration1R1G1B
    Package modeSMD3528
    Pixel resolution64 pixels (W) x 32 (H) pixels
    Max power consumption18W
    Module thickness13mm (without magnet)
    25mm ( with magnet)
    Weight0.5kg
    Drive typeConstant drive
    Scan mode1/ 16 scan
    Port typeHUB75-A
    Brightness of white balance≥1,500cd/sqm
    CabinetDimension640 x 640mm or 960 x960mm
    Quantity of module8pcs or 18pcs
    Power supply5V 60A x 1pcs or 3pcs
    Thermal dischargeFan x 0pcs
    Pixel per cabinet128 x 128 pixels or 256 x256
    Best viewing distance4-30m
    Best viewing angles(H/V): 160°/120°
    TemperatureStorage: -35 - +85℃
    Working: -20 - +50℃
    Operation humidity10% - 95%
    Thickness100mm
    PowerWorking voltageAC 220V ±10%
    Average power consumption180W/ sqm
    Max power consumption≤550W/ sqm
    Current≤20mA (single LED)
    Main technical parameterDriving deviceConstant current driving IC
    Refresh rate≥1,920Hz
    Grey scale256 levels of each color (RGB)
    Colors16.7m colors
    MTBF≥100K hours
    Power switchAutomatic switch
    Display mode800 x 600/ 1,024 x 768

    Features
    • High contrast and high image quality.
    • Smooth surface,Ultra high definition LED display, high resolution brings delicate display effect.
    • Wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability.
    • Light weight,easy to assemble and dismantle.
    • Maintenance can be a single point or single lamp.
