Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch

Shenzhen Haojingyuan Optoelectronic Co.,Ltd
Contact Now
    Buy cheap Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch from wholesalers

    Buy cheap Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch from wholesalers
    • Buy cheap Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch from wholesalers
    • Buy cheap Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch from wholesalers

    Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch

    Ask Lasest Price
    Brand Name : HJY
    Model Number : P2.5
    Certification : CE FCC
    Price : Negoniate
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 3000sqm per month
    Delivery Time : 15-20days after receiving deposit
    • Product Details
    • Company Profile

    Stage Events Indoor Rental LED Display Video Wall Die Casting 2.5mm Pixel Pitch


    Stageevents signs video wall die casting Indoor Rental LED Display P2.5 led


    sign


    Features


    1. Truly seamless: precision metal structure, to achieve high-quality seamless effect, the display uniform.

    2. Fast dynamic picture processing capability: nanosecond response time in dealing with fast moving images, smearing, ghosting does not appear.

    3. High Brightness: Brightness up 1200nit, higher than the brightness of the LCD and DLP rear projection, and can automatically adjust.

    4. High Contrast: High quality LED lamp black, with a black mask, the contrast up to 5000: 1.

    5. High gray: up to 16bit gray scale performance in low-light display gray scale performance is still intact.

    6. High refresh rate: the display is stable, no ripples, no flicker, display real and natural.

    7. Long life: life up to 100,000 hours, brightness decay to half the life expectancy of up to 50,000 hours.


    Unit ModuleItemparameter
    Modelp2.5 indoor led display
    Module size160mm*160mm*10mm
    Pixel Pitch2.5mm
    Pixel Density160000dots/m2
    Pixel Configuration1R1G1B
    Package modeSMD2121
    Module Resolution64dots(W)*64dots(H)
    Max power consumption20w
    Module Thickness10mm(without magnet) 13mm (with magnet )
    Module Weight0.21kg
    Driving MethodConstant Current Driving
    Scan Method1/32scan
    Interface WayHUB75E
    Brightness≥1000cd/m2
    Unit Moduledimension640mmx640mm
    Quantity of Module16
    Thermal dischargefan 1pcs
    Power supply Mode5V/40A* 1pcs
    Pixel per cabinet256mm*256mm
    Thickness85mm
    Optimal Viewing Distance2M-10M
    Optimal Viewing angle120°(W)120°(H)
    Enviroment TemperatureStorage :-35ºC-+85ºC
    work :-20ºC-+50ºC
    PowerRelative Humidity20%-90%
    Operating VoltageAC220V±10%
    Average power consumption≤200W/m2
    Max power Consumption≤300W/m2
    Current≤20mA (Single LED )
    Control systemCPUPentium4 or above P4 or above
    Operate systemWIN98/2000/NT/XP
    Control ModeSynchronization with PC
    Main technical parameterDriving DeviceIC Constant current driving
    Refresh Rate≥400HZ
    Gray/ColorRGB each 256 grade, can display 16.7M clolor
    MTBF≥9000hours
    Power SwitchAutomatic Switch
    Display Mode800*600/1024*768

    1. After-sales service:

    1) Service principles: Response in time, solve problems as soon as possible and ensure the use.
    2) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
    3) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
    4) Under normal use and storage, Our Company will be responsible for the equipments.


    2. Pre-sales service:

    1) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time. Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
    2) Our company can train the users based on the manual. The training include system use, system maintenance and equipment protection.
