    Full Color P5 LED Advertising Display Waterpoof High Brightness Large Viewing Angle

    Ask Lasest Price
    Brand Name : HJY
    Model Number : P5
    Certification : CE FCC
    Price : Negoniate
    Payment Terms : T/T, Western Union, MoneyGram
    Delivery Time : 15-20days after receiving deposit
    • Product Details
    • Company Profile

    Full Color P5 LED Advertising Display Waterpoof High Brightness Large Viewing Angle

    China manufacturer LED Advertising Display P5 full color waterpoof led sign


    Features of P5 led module:


    1. High quality LED chip and high anti-static electricity capacity.

    2. Large viewing angle and smooth displaying provide excellent visual effect from every angle.

    3. The integration of lamp and driving IC,together with with the multi-circuit structure,achievs evenly-distributed current,low power consumption and fast heat dissipation.

    4. Ultra high brightness,low attenuation,high reliability and weather ability.

    5. High contrast ratio.Adopting black lamps can improve the contrast ratio by 50%.

    6. High refresh rate,high gray scale,ghost-canceling,low power consumption,low EMI,anti-creeping,multi-route redundancy backup-supporting,and dot-by-dot-calibration.


    Application scopes of P5 led module: Widely applied to traffic information distribution of station, quay and airport, conference, shopping mall, brand presentantion,TV station, stage show, concert and so on.


    Specification of led module:
    Led display modulePixel pitch5 mm
    Module size160mm*160mm
    Pixel density40000 dots/sqm
    Brightness≥6000 cd/sqm
    Screen life≥100000 hours
    pixel composition1R1G1B
    LED chipEpistar
    Module resolution32*32(dots)
    ConfigurationSMD 3in1
    Led display cabinetCabinet size (W*H*D)960*960*110(mm)
    Cabinet resolution192*192(dots)
    Module quantity36pcs
    Average Power Consumption300w
    Max. Power Consumption1000w
    MaterialDie-casting aluminum cabinet
    Protective gradeIP65
    Cabinet Weight23.34kg

    1. What are Pixel Pitch, Pixel Density, LED QTY, and Pixel Configuration?
    Pixel Pitch is the distance between neighboring pixels.
    Pixel Density is the quantity of pixels per square meter.
    LED QTY is the quantity of LED lamps per square.
    Pixel Configuration is the description of the consistence of a pixel, for instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.
    2. What are LED Type, Module size and Module resolution?
    LED Type is the description of LED lamp, for instance, the brand, the shape in physical, the size of the lamp, etc.
    Module size is the measurement of a module.
    Module resolution is the number of pixels per module.
    3. What is Drive Method, driving IC and Power supply?
    Drive Method: always we use static, 1/2scan,1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.
    Driving IC is the generic term for several kinds of IC, that are used to control the LED lamps, and as a bridge between the control system and lamps.
    Power supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.
    4. What is viewing angle?
    Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.


    Normal question
    1. How long could I receive the inquiry reply?
    You will get a reply within 24 hours.
    2. What’s your warranty?
    Two years warranty, whole life maintenance.
    3. What’s your leading time?
    Production normally takes 20-30 days.
    4. What’s your term of delivery?
    We accept EXW, FCA,FOB, CFR, CIF, DDU, etc. You can choose anyone which is most convenient to you.
